Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck

Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck
Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck

बड़ी छवि :  Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck

उत्पाद विवरण:
उत्पत्ति के प्लेस: चीन
ब्रांड नाम: Howo
प्रमाणन: ISO CCC
मॉडल संख्या: jnhtc
भुगतान & नौवहन नियमों:
न्यूनतम आदेश मात्रा: 1 इकाई
मूल्य: USD23100-25410
पैकेजिंग विवरण: नंगा
प्रसव के समय: 45 कार्य दिवस
भुगतान शर्तें: एल/सी, टी/टी
आपूर्ति की क्षमता: प्रति सप्ताह 50 यूनिट

Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck

वर्णन
घोड़े की शक्ति: 371 एचपी रंग सफेद: हरा या अन्य
ईंधन टैंक: 400 एल ड्राइव व्हील: 8x4
टायर: 12.00R20 क्षमता (भार): 20टी
प्रमुखता देना:

Howo TX Tipper Truck 380HP

,

8x4 dump truck 20 cubic

,

Heavy duty dump truck 400HP

Howo TX Tipper Truck 380HP 400HP 8x4 20 Cubic Canter Dump Truck
Key Specifications
Attribute Value
Horsepower 371hp
Color White, Green or other
Fuel Tank 400L
Drive Wheel 8x4
Tyres 12.00R20
Capacity (Load) 20T
Technical Specifications
Model ZZ3257V3847B1
Driver's Cab HW76 extended cab, with one sleeper berth, with air conditioner, air seat for driver. MP3
Engine
  • Model: WP12.400E201, Euro II emission standard
  • 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling
  • Maximum output: 400PS (294kW) at 2100 rpm
  • Maximum torque: 2060Nm at 1200-1500rpm
  • Bore: 126mm Stroke: 155mm
  • Displacement: 11.596L
  • Brand: Weichai
Steering
  • Model: BOSCH
  • Hydraulic steering with power assistance
  • Left hand driving
Clutch Φ430 Pull-type diaphragm spring clutch
Transmission
  • Model: HW19710, 10 forward and 2 reverse
  • Manual type
  • With transmission power take-off HW70
  • Max Torque: 1900N*M
Front Axle
  • Model: HF9
  • Drum brake system
  • Rated loading capacity: 9000kgs
Rear Axle
  • Model: MCP16ZG
  • Capacity: 16000kgs
  • Drum braking steering axle, self-adjusting arm
Wheelbase 3800+1350 mm
Brake System
  • Type: Wabco braking system
  • ABS 4S/4M
  • Engine exhaust valve brake
Oil Tanker 300L aluminum alloy fuel tank
Tires
  • Types: 12.00R20 radial tire; 18PR
  • 10 pcs, plus one pc spare tire
Bumper Metal bumper
Dump body
  • 5600*2300*1500mm
  • 8mm for bottom and 6 mm for side plate
  • Rectangular box
  • Chinese brand front lifting cylinder
  • With integral fender, headlight cover
Dimensions
  • Front wheel track (mm): 2022
  • Rear wheel track (mm): 1830
  • Overhang(front/rear) (mm): 1500/1870
  • Overall Dimension (mm): 8650*2580*3450
Weight
  • Dead weight (kg): 13500
  • Gross vehicle weight (kg): 25000
